OPENROAD^® Flight case for 27" monitor on adjustable VESA bracket

Ref. FVE OS-27.1

Similar references :

See details

Solution ready-to-use for fast setup and immediate operation.
Removable flat front lid for quick installation, connection, and use of the monitor with no downtime.
Simplified rear technical access with hinged rear hatches for fast intervention on wiring, connections, and cablingno disassembly required.
Stable operation with rubber feet to reduce vibrations, protect surfaces, and ensure a secure position during use.
Standard monitor compatibility: VESA 75/100/200 mount to fit many screens, with adjustable tilt (up/down) for a comfortable viewing angle.
Optional stand mounting: pre-drilled hole for Manfrotto 179 Rapidapter fixation (not supplied).
Developed and manufactured by Rythmes & Sons in France

Manufacture on demand

717.60€ Incl. VAT

Public price

Rate code : F02

Lock for Open Road^® cover
Ref. ORO S001 65
9.72€ Incl. VAT

Technical specifications

Product reference

FVE OS-27.1

Net weight (kg)

14.60

Screen size (inch)

27"

Displays dim. LxHxD (mm)

630 x H380

Quantity per case

1 display

Overall dimensions with wheels (mm)

240x710xH510

OPENROAD^® Flight case for 27" monitor on adjustable VESA bracket

OPENROAD^® flight case for 27" video control monitor, designed for secure transport and fast installation in professional environments.

Ideal for mobile control rooms, TV studios, live production, event staging, or broadcast facilities.

The integrated VESA mount allows the monitor to be securely fixed inside the flight case. The adjustable VESA system provides an up/down tilt function, ensuring optimal viewing depending on the installation height (control room, desk, rack, or stage setup). Once adjusted, the tilt angle is mechanically locked to guarantee stability and safety during operation, while remaining fully protected during transport.

A dedicated mounting hole is integrated underneath the case to allow attachment of a Manfrotto 179 Rapid Adapter receiver (not included), enabling quick installation on compatible stands

Product specifications and fittings

Cabinet-style configuration
OpenRoad^® removable flat lid at the front
9 mm Brown phenolic faced birch plywood
2 recessed sliding latches
3 recessed spring-loaded handles with double sprung
2 Hinged back access doors
4 rubber feet
Hole below for fixing Manfrotto 179 Rapiadapter cup (not supplied)

Interior features

Adjustable metal VESA 75/100/200 bracket 1 angle (up / down) on the rear side
For monitors dim. 630x H380 mm maximum

Developed and manufactured by Rythmes & Sons in France

Download PDF file
