Multi-core cable trunk 1200x600x400 with two columns

Multi-core cable trunk 1200x600x400 with two columns

This Classic trunk is delivered with 2 vertical columns. They are used as a guide when coiling cables into the trunk. You can wrap the cables in eight around both columns or wrap the cables in a circle around one of the columns. The trunk is equipped with two cable gland in U-Dish which allows the cable to leave the trunk while leaving the rest of the cable inside the trunk.

Product specifications and fittings

• Trunk-style design
• Hinged top lid
• Heavy-duty 9 mm birch plywood with black Hexagonal Pattern
• 2 large recessed butterfly latches with guided opening/closing mechanism
• 2 lid stays (rear-mounted in recessed dish)
• 8 recessed spring-loaded handles with double sprung
• 4 swivel castors Ø100 (2 with brake) on mounting plates
• 4 recessed stacking dishes
• 2 recessed dishes with cable passage at the ends

Interior features

• 2 columns to wrap the cables in the shape of 8
• Parts in the lid for the mechanical hold of the columns

Developed and manufactured by Rythmes & Sons in France
